SINOTRUK HOWO 4x2 CAR RECOVERY TRUCK
Model |
ZZ1107G451CD1 |
|
Cabin |
2080 Single Cabin, with three seats and one bed, with Air Conditioner |
|
Engine |
Model |
Cummins ISF3.8S3141 |
|
Horse Power (Hp/rpm) |
141/2600 |
|
Max.Toruqe(Nm/rpm) |
440/1200-2200 |
|
Displacement L |
3.76
|
|
Type |
DIESEL, 4-cylinder in-line with water cooling, turbo charger and intercooling, 4-stroke common rail diesel engine |
Transmission |
WLY6T51, 6 speeds forward and 1 speed reverse. |
|
Front Axle |
Steering with double T-cross section beam. 2.4T |
|
Driving Axle |
4.2T, Pressed axle housing ratio:4.875 |
|
Suspension |
Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: leaf semi-elliptic springs, bogie spring and stabilizer |
|
Steering System |
Hydraulic steering with power assistance |
|
Brake System |
Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating |
|
Tire |
7.50R16 |
|
Fuel Tank Capacity (L) |
120L Aluminum Diesel Tank |
|
Kurb Weight (kg) |
5,400 |
|
Loading Capacity (kg) |
3,000 |
|
Rated recovery capacity(kg) |
2,000 |
|
Gross Vehicle Weight (kg) |
8,400 |
|
Length of Loading Bed(mm) |
5,600 |
|
Overall Dimension(L*W*H)(mm) |
7100×2200×2650 |
|
Wheelbase(mm) |
3800 |
|
Max. Speed (km/h) |
95 |
